New look Landboss 800D and full-length poly windscreen now included as standard fitment.



Purpose built for the Aussie market in right hand drive, the Landboss 800D diesel UTV is ready to work.



Tough steel chassis, powered by a dependable Kubota diesel engine and equipped with a large steel tipper tray with removable drop down sides to cater for all occasions.



Durable, Dependable and ready to work. Landboss.

Landboss 800D does not come with a winch. Note gallery images of the vehicle display a winch, which can be purchased as an optional extra. National ride away prices are inclusive of freight to your local dealer and dealer pre-delivery charges. Excludes Regional WA dealers.

KEY FEATURES

  • NEW look 800D with updated front end styling
  • NEW full-length poly windscreen
  • Right hand drive (RHD)
  • 19.3 hp Kubota 3 cylinder Japanese diesel engine
  • 45Km/h top speed
  • Canadian CVTech transmission
  • Electronic power steering (EPS)
  • Selectable 2WD/4WD with front & rear differential lock, turf mode
  • Durable 26 inch 4 ply tyres mounted to 14 inch black steel wheels
  • Independent dual, A- Arm suspension both front and rear
  • Front and rear tow pack to move a hefty 600kg
  • Steel tip tray with removable drop down sides and a 450kg carry capacity
  • Reverse beeper, a 3 seat bench seat with seat belts for added safety
  • ROPS certified roll frame
  • Roof kit
  • Full lights package, horn and side mirrors are all standard features
  • Available in Orange
  • 2 year parts and labour warranty

GALLERY

*Model shown in photos with optional winch, rear view mirror and steel side steps.
DOWNLOAD BROCHURE
FIND A DEALER

SPECIFICATIONS

Engine Type

19.3 hp, In Line 3 Cylinder, Water Cooled Kubota Diesel

Engine Model

Kubota D782-E3B

Cooling

Liquid Cooled

Bore & Stroke

67 x 73.6 mm

Compression Ratio

24:1

Maximum Torque

49 Nm @ 2400 rpm

Starter System

Electric

Battery/AMP Hour

12Volt, 45Ah

Lubrication System

Forced Feed

Transmission

CVTech High / Low / Neutral / Reverse, 2WD / 4WD, Front & Rear Differential Lock

Clutch

Constant Variable Transmission (CVT)

Final Drive

Shaft Drive

Front Brakes

Hydraulic Disc

Rear Brakes

Hydraulic Disc

Parking Brake

Handbrake

Steering

Electronic Power Steering (EPS)

Drive

Right Hand Drive (RHD)

Front Suspension

Dual A-Arm Coil Over Shock

Rear Suspension

Dual A-Arm Coil Over Shock (IRS)

Tyres (front/rear)

26x9x14 / 26x11x14

Wheels

Front 14×9 / Rear 14×11

WheelsSteel

5 Stud

Dimensions (L/W/H)

3018mm / 1520mm / 1905mm

Wheel Base

1,930mm

Distance between Wheels

990mm

Ground Clearance

240mm

Dry Weight

700kg

Fuel Capacity

35 litres

Cargo Box Capacity

450kg

Rear Tray (L/W/H)

1020mm / 1470mm / 400mm

Towing Capacity

600kg

Warranty

2 Years Parts & Labour

Colour

Orange

Standard Features

Roof kit & full-length poly windscreen
